Product information
The requirements on bathroom construction sites vary; sometimes there is more, sometimes there is less space available. One thing however remains the same: customers would like a long-lasting, aesthetic solution. This is where the Fundo Flex comes into play. If you are looking for a slim, versatile, and easy-to-install solution, this channel element with a particularly narrow channel profile is the perfect choice.
With a width of only 35 mm, the channel profile fits perfectly into any bathroom design and thanks to its unique ability to move, rotate and precisely align with the wall, offers maximum installation flexibility, and allows for exacting designs. Thanks to its stepped rebates on either side, the Fundo Flex can be securely connected to sloping boards completing the installation into a fully sealed shower floor. What’s more, it also allows for the linear drainage to be positioned close to wall, centralised or anywhere in between! Trust the proven wedi quality granting you freedom in design and maximum flexibility during the installation - choose the Fundo Flex for your next project.
Aesthetic
Flexible
Hygienic
Robust
Integrated
Technical Details
Scope of delivery
1 × Fundo Flex channel element
1 × insert, pre-mounted
1 × eccentric, pre-mounted
1 × cap tool
1 × removal aid
| Technical properties | |
|---|---|
| Material | XPS core with mortar coating |
| Minimum tile size for wheelchair accessibility | 50 x 50 mm |
Usage
- In private housing
- In publicly accessible buildings and workplaces according to DIN 18040 Part 1
- In barrier-free apartments according to 18040 parts 1 and 2 (Observe the minimum tile size specification for planned wheelchair load, see technical characteristics)
- As a structural waterproofing in combination with tile and panel coverings for the water impact class W2-I according to DIN 18534 Part 6
Install the Fundo Flex on the screed
Install the Fundo Flex on a wooden floor
