Product information
The wedi Sanwell niche is a factory-made, prefabricated, tileable wall element made from wedi building board. The joints are sealed in the factory ensuring watertightness, so time consuming construction is not required.
The wedi Sanwell Niche solutions are practical and aesthetically pleasing. Their spacious design highlights their extravagant character in any bathroom and also provides convenient storage space.
Particularly in smaller guest bathrooms, where space is restricted , these wedi elements can offer storage space for a range of shower accessories.
Technical Details
Technical properties of the wedi Sanwell niches | |
---|---|
Niche, 20 / 40, Frame width 10,0 mm | |
Length (Interior dimensions / Exterior dimensions) | 234 / 454 mm |
Width (Interior dimensions / Exterior dimensions) | 434 / 654 mm |
Depth (Interior dimensions / Exterior dimensions) | 100 / 110 mm |
Weight (without packaging) | 2,200 kg |
Niche, 30 / 60, Frame width 10,0 mm | |
Length (Interior dimensions / Exterior dimensions) | 334 / 554 mm |
Width (Interior dimensions / Exterior dimensions) | 634 / 854 mm |
Depth (Interior dimensions / Exterior dimensions) | 100 / 110 mm |
Weight (without packaging) | 3,110 kg |
Niche, 20 / 40, Frame width 12,5 mm | |
Length (Interior dimensions / Exterior dimensions) | 234 / 372 mm |
Width (Interior dimensions / Exterior dimensions) | 434 / 572 mm |
Depth (Interior dimensions / Exterior dimensions) | 70 / 82,5 mm |
Weight (without packaging) | 1,260 kg |
Niche, 30 / 60, Frame width 12,5 mm | |
Length (Interior dimensions / Exterior dimensions) | 334 / 472 mm |
Width (Interior dimensions / Exterior dimensions) | 634 / 772 mm |
Depth (Interior dimensions / Exterior dimensions) | 70 / 82,5 mm |
Weight (without packaging) | 2,45 kg |
Downloads
Brochure - Bathroom inspiration
Brochure - Spa and wellness
Brochure - Special solutions for suspended timber floors
Brochure - wedi at a glance
Brochure - wedi world of systems
Assembly instruction Sanwell Niches
Certificat - GEV EMICODE for wedi 610 Joint Sealant
Sanwell Niches 20-40-10
Sanwell Niches 20-40-7
Sanwell Niches 30-60-10
Sanwell Niches 30-60-7
Usage
- For private and commercial use indoors with direct contact with process and cleaning water.
- The base must be sufficiently load bearing and even.
- The wedi Sanwell niche can be combined with the wedi sealing systems building board, Subliner Dry, Subliner Dry & Flex and wedi 520.
