Product information
The Fundo Discreto attachment element is the perfect alternative to drainage channels and creates an optical illusion of the water flowing from the floor into the wall. Specially developed for the Riolito Neo, Riolito and Plano Linea shower elements, it has a new high-quality stainless steel cover which can be used on both sides, even after installation. A tileable variant is thus available in addition to the attractive stainless steel look. Installation is easier than ever as a result: the mounting is adjusted with nothing but a screw and is mechanically guided on a slide. There’s also no need to stick the height adjustable and tileable angular sheet above the cover. As a result, the tiled section is individual there, but also always matches. This guarantees particularly high stability and quick installation on site.
- The channel length for the shower element determines the appropriate Fundo Discreto variant.
- The cover can be used and mounted on both sides (visible side V2A brushed or tileable as desired).
- Height adjustable and tileable angular sheet
- Adjustment with just one screw
Technical Details
Cover made of V2A stainless steel, both sides can be used (1st side: brushed surface, 2nd side: can be tiled). It can be set to a tile thickness of 5 to 20 mm (wall and floor). Adjustment is made with a stencil (included in scope of delivery). The whole element width corresponds to the Riolito width.
wedi Fundo floor elements can be cut to size on site, the geometry of the elements should be maintained however. wedi fundo elements can only be combined with the wedi Fundo drains.
| Technical properties Fundo Discreto | |
|---|---|
| Distance of floor tile and cover | 7 mm |
| Dimensions of cover (length x height x thickness) | 280 x 67 x 22,5 mm |
| | 680 x 67 x 22,5 mm |
| | 780 x 67 x 22,5 mm |
| | 880 x 67 x 22,5 mm |
| | 1.080 x 67 x 22,5 mm |
| Installation depth, horizontal | 150 mm |
| Structural height on Riolito | 154 mm |
Downloads
Usage
- In domestic residential construction
- In publicly accessible buildings and workplaces complying with DIN 18040 part 1
- In accessible dwellings complying with DIN 18040 part 2 (note specifications for minimum tile size if wheelchair access is planned, see technical properties)
- As a construction seal combined with tile and slab coverings of load class A0, and A (floors subject to moderate surface flowing water in interior areas; directly loaded floors in rooms in which tap water or cleaning water is used very frequently or for long periods)
